Brand: ECO-WORTHY

Color: w/ Combiner Box&Inverter

Features:

• High-efficiency silicon solar cells ensure high performance of solar modules and create maximum power output. 25-year transferable power output warranty: 5-year/95% efficiency rate, 10-year/90% efficiency rate, 25-year/80% efficiency rate.
• Easy way to provide power for sheds, light poles and gates without the need for trenching and laying cables.
• Great for camping or remote cabins. Power devices in remote back country locations.
• The system has the capability of withstanding heavy snow and strong wind loads.
• Auxiliary power for RV's. Popular with commercial RV retrofitting.

Publisher: ECO-WORTHY

Details: 100W Poly Solar Panel
Related power: 100W
Open circuit voltage (Voc): 21.6V
Max power voltage (Vpm): 18V
Short circuit current (Isc): 6.11A
Working current (Iop):5.55A
Output Tolerance: ±3%
Temperate coefficient of Isc: (0.10+/- 0.01 )%/ ℃
Temperate coefficient of Voc: - (0.38 +/-0.01 )%/ ℃
Temperate coefficient of power Voc: -0.47%/℃
Temperature range: -40℃~+80℃
Frame: Heavy duty aluminum
Kind of connection: waterproof junction box, can be customized
Guarantee of power: 90% with in 10 years 80% with in 25 years
Kind of glass and its thickness: Low Iron, high transparency tempered glass of 3.2mm
SLA Battery Voltage: 12V
Size: 39.3*26.2*1.38in (996*665*35mm)

1500W 24V-110V Off Grid Pure Sine Wave Inverter
Output Volt:100/110/120VAC
Continuous Power:1500W
Surge Power:3000W
Frequency:60Hz
Efficiency:>90%
USB Output:5V
Input Range:21-30VDC
Working Input:24VDC
Fuse:20A
Low battery alarm:21+0.5V
Low battery shut down:20+0.5V
Over voltage shut down:30.5+0.5V
Over load shut down:1800W over 10 seconds
Over heating shut down:>75℃
Over Thermal Protection:shut down the output
Working Temperature:-10℃~+50℃


Solar Combiner Box
Model: ECO-PV6
Input Circuits/Circuit Breakers: 6
Circuit Breaker Rating: 10A
Max Total DC Output Current: 60A
Max Input Voltage Rating: 250V
Max Output Voltage Rating: 250V
Protection Grade: IP65
Operational Environment Temperature: -30℃~+70℃
Relative Humidity: 0-95%
Cooling Method: Natural Cooling
Surge Lightning Protection: Yes
Dimensions: 10.3"x12.6"x4.5" (260*320*115mm)

Package Included:
8pcs 100W Polycrystalline Solar Panel
8 sets Z Style Mounting Kits
1pc 60A Solar Controller
1pc 1500W 24V-110V Off Grid Pure Sine Wave Inverter
2pcs 5m(16.4') 12AWG Solar Cables (totally 32.8')
1pc 6-String Solar Power Combiner Box

UPC: 788568241928

EAN: 0788568241928
